STONET M6 WiFi6 HOME MESH SYSTEM AX1800, 2pack (DECO)

Product detailed description

Router AX1800 WiFi6 MESH
Stonet router M6 nabízí celodomácí síťové řešení Mesh WiFi. Díky jedinečné technologii Easy Mesh můžete snadno vytvořit distribuovanou síť po celém vašem velkém domě. Nejnovější technologie Wi-Fi 6 vám nabídne současné dvoupásmové připojení s bezdrátovými rychlostmi 1201 Mb/s v pásmu 5 GHz a 573 Mb/s v pásmu 2,4 GHz. Vestavěný s 880MHz dvoujádrovým CPU, 128M bajtů DDR3 RAM a 16M bajtů flash, M6 zajišťuje, že vám poskytne vysoký výkon pro různé síťové aplikace. Díky technologii OFDMA & MU-MIMO podporuje M6 více zařízení pro přenos dat najednou. strana

Wireless
Standards

WiFi 6

IEEE 802.11ax/ac/n/a 5GHz

IEEE 802.11ax/n/b/g 2.4GHz

Signal Rate

AX1800

5GHz:1201Mbps (802.11ax)

2.4GHz:574Mbps (802.11ax)
Mesh Network Standard
Easy Mesh
WiFi Range
2.4-2.4835GHz and 5.150~5.85GHz
3 Bedroom Houses

4×Fixed High-Performance Antennas

Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming

Concentrates wireless signal strength towards clients to expand WiFi range

Improves transmission power to strengthen signal coverage

WiFi Capaciyt

Dual-Band:

Allocate devices to different bands for optimal performance

OFDMA:

Simultaneously communicates with multiple Wi-Fi 6 clients

Airtime Fairness:Improves network efficiency by limiting excessive occupation

4 Streams:Connect your devices to more bandwidth

Work Modes
Router Mode, Access Point Mode
Hardware

Processor
880MHz Dual-Core CP
Ethernet Ports
1*Gigabit WAN Port

1*Gigabit LAN Port


LED Indicatiors
SyS,LAN,Mesh(wps),WAN
Button
Mesh,Reset
Antenna
4*Internet fixd 5dBi antenna
Power Supply
12V/1A
Security

WiFi Encryption
WPA,WPA2,WPA/WPA2,WPA3
Network Security

Access Control,Application Layer Gataway

Guset Network
1*5GHz Guest Network

1*5GHz Guest Network

Software
Protocols
IPv4,IPv6
WAN Types
Dynamic IP,Static IP,PPPoE,PPTP,L2TP
Quality of Service
QoS by Device
NAT Forwarding
Port forwarding,port triggering,DMZ,UPnP
IPTV

IGMY Proxy,IGMP Snooping,Bridge,TAG VLAN
DHCP

Address Reservation,DHCP Client List,Server
DDNS
NO-IP,DynDNS
Physical

Dimensions(W*D*H)
104*104*96mm

Package Contents
WiFi 6 Mesh Router

Power Adapter

Quick Installation Guide

Other

Systems Requirements

Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)


Certifications
FCC,CE,RoHS

Environment
Operating Temperature: 0?~40? (32? ~104?)

Storage Temperature: -40?~70? (-40? ~158?)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

Test DATA

WiFi Transmission Power
CE:

<20dBm(2.4 GHz)

<23dBm(5.15 GHz~5.25 GHz)

FCC:

<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz)
Kód produktu: AGM82115
Part no.: M6 2-PACK
EAN: 6972012671728
